Physical Ports
8 × 10/100/1000BASE-T Gigabit RJ45 ports with IEEE 802.3at PoE+
4 × 10GBASE-SR/LR SFP+ slots, backward compatible with 1000BASE-SX/LX/BX SFP modules
RJ45 to DB9 console interface for management

Silent Fanless Design and Heat Dissipation
Completely fanless for silent operation, perfect for offices, healthcare facilities, and meeting rooms
Advanced heat dissipation for stable performance under continuous operation

Compact 12-inch Form Factor for Flexible Deployment
Fits in tight spaces ideal for retail stores, hotels, branch offices, and IoT deployments
Rack-mount, desktop, or wall-mount option for easy installation anywhere
Enterprise-level networking without requiring a dedicated server room

Intelligent PoE+ for Cost-effective Powering
8 PoE+ ports delivering up to 120W, ideal for Wi-Fi 6 APs, IP cameras, VoIP phones, and IoT devices
Smart PoE scheduling for reducing power consumption and optimizing energy efficiency
6KV surge protection for reliable operation in harsh environments
Advanced PoE control for enabling/disabling port functions, priority management, and power scheduling

Enterprise-grade Reliability for 24/7 Operation
VRRP for redundant routing for seamless failover
ERPS (Ethernet Ring Protection Switching) for rapid failover recovery in under 10ms
ISSU (In-Service Software Upgrade) for updating firmware without interrupting network traffic

IP Routing and Multicast Support
IPv4/IPv6 dual-stack routing with static routing, RIPv1/v2, RIPng and OSPFv2/v3
VLAN-based routing for segmenting networks for optimized performance
IGMP v1/v2/v3 snooping, fast leave, MVR and IGMP filtering for efficient multicast traffic management
MLD v1/v2 snooping and optimized IPv6 multicast support

Optimized Layer 2 and VLAN Management
4K VLANs, Q-in-Q, selective Q-in-Q, GVRP, Private VLAN and Voice VLAN
Link Aggregation (LACP, static routing) with 64 groups, up to 8 ports per group
STP, RSTP, MSTP, BPDU guard, root guard, and loop protection
LLDP and Cisco UDLD compatibility for enhanced device discovery and link integrity

Quality of Service  for Traffic Optimization
8 priority queues per port with SP, WRR and hybrid scheduling
Traffic classification based on 802.1p, DSCP, CoS, and VLAN priority
Advanced traffic shaping, WRED, and flow monitoring for superior network efficiency

Comprehensive Security and Access Control
IEEE 802.1X authentication (port/MAC-based) and RADIUS/TACACS+
L2/L3/L4 ACL filtering for advanced security enforcement
DHCP Snooping, IP Source Guard, and Dynamic ARP Inspection to prevent unauthorized access
DDoS protection against TCP SYN Flood, UDP Flood, and broadcast storms

Advanced Management and Monitoring
CLI (Console/Telnet), Web GUI, SNMP v1/v2/v3 and RMON for flexible management
Secure remote access with SSH, HTTPS, TLS, and SNMPv3 encryption
sFlow traffic monitoring for real-time network insights
PLANET Smart Discovery Utility for deployment management
PLANET NMS for deployment management
PLANET NMSViewerPro for deployment management
